Mini base cabinets are the underestimated gap fillers of kitchen planning. The Nobilia UDI30-43 with 30 cm width and 57.6 cm carcase height fits under hobs, seating areas or wall projections – with an internal drawer for hidden extra storage space.

Technical data:
• Width: 30 cm | Carcase height: 43.2 cm (43.2 cm)
• Side depth selectable: 56.1 cm (standard) or 46.1 cm – both free of charge in the configurator | Special depth 35 cm carcase depth on request (order by phone or email) | Total depth incl. front: approx. 58.2 cm (56.1 cm) or 48.2 cm (46.1 cm)
• Drawer system: nBOX slate grey | Side height: 10.7 mm
• Design: 1× internal drawer
• Damping: SoftStoppPro bidirectional (Soft Close & Soft Open)
• Optional: Push-to-open (MP-PTOSA 7962) at extra charge | For Line ONE types: standard
• Load capacity nBOX: drawer max. 30 kg | pull-out max. 30–55 kg (depending on width/depth) | Total cabinet load capacity 40–70 kg
• 5-year manufacturer warranty | Made in Germany

PEFC certificate: the wood in the Nobilia cabinet comes from sustainably managed forests – checked annually by independent bodies. White interior carcase as standard: white reflects light, shows dirt immediately and makes cleaning easier. Optional in slate grey at extra charge (MP-KID 7947). Hardwood dowels 8×30 mm with water-resistant glue connect all carcase parts – no clip system, no plastic connectors.

Scope of delivery:
• Ready for installation from the factory – the cabinet comes assembled, you set it up.
• High-quality Nobilia installation material included.
• Plinth package free of charge: front panel 220 cm, side strip 110 cm, connectors (90° + 135°).
• Plinth height: 7 / 10 / 15 / 20 cm | Colour selection via the cabinet configurator.

11 years as a Nobilia partner: direct factory shipping, free shipping, approx. 3–4 weeks. Personal contact in Frankfurt am Main for nBOX configuration, planning compatibility and system height coordination.

For extensions to existing Nobilia kitchens: always use the colour number from the purchase contract – not the dealer name. Dealers assign their own names for Nobilia ranges. We work exclusively with Nobilia original codes.
